This camera is one form of a camera spy mounted clock hidden camera can be placed anywhere and stay monitored through your television.
SPECIFICATIONS:
Imaging Sensor: 1/3-inch CMOS
CMOS total pixels: PAL: 628*582
Transmission/Receiving Frequency: 2.4GHz/1.2GHz
Built-in microphone for audio monitoring
Transmission Power: 10mW/CE; 2mW/FCC
Valid Distance: 50m-100m (without block)
Horizontal Definition:380 TV Lines
Minimum Illumination:1.5Lux / F1.5
Frequency System: PAL
Power Adapter: Receiver: DC9V-12V/500mA
Camera: DC8V/500mA
Operating temperature: -10 to +50 CELCIUS
Time clock powered by AA battery
Camera size: 145x145x34mm
How to use:
1. Connect antenna to the receiver.
2. Plug-in power adaptor of DC 9V/12V power supply into the power socket of the receiver (the power indicator is on).
3. Connect the output of receiver with monitor with AV cable.
4. Plug-in power adaptor of DC 8V power supply into the power socket of the camera (battery of the same voltage is acceptable).
5. Fine tune to the desired position (until the image of wireless camera is received).
6. Adjust the lens of the camera to best position.
What you get:
1* Wireless Color Camera with Built-in Microphone
1* Wireless Flip-type 4-channel AV Receiver
1*8V Power Adaptor for Camera
1*9V Power Adaptor for Receiver
1*Swivel Bracket for Camera
1*Antenna for Receiver
1*AV cable
Indonesia language :
Camera yang satu ini adalah berbentuk sebuah jam yang terpasang camera tersembunyi jadi bisa anda tempatkan dimana saja dan tinggal dipantau lewat televisi anda aktifitas yang terekam oleh kamera ini. Sangat berguna bagi orang yang mempunyai toko dan hotel untuk mengawasi para karyawannya.
SPESIFIKASI:
Imaging Sensor: 1/3-inch CMOS
CMOS total pixels: PAL: 628 * 582
Transmisi / Menerima Frekuensi: 2.4GHz/1.2GHz
Built-in microphone for audio monitoring
Transmisi Power: 10mW/CE; 2mW/FCC
Valid Distance: 50m-100m (tanpa blok)
Horizontal Definition: 380 TV Lines
Minimum Illumination: 1.5Lux / F1.5
Frekuensi System: PAL
Power Adapter: Receiver: DC9V-12V/500mA
Kamera: DC8V/500mA
Suhu operasi: -10 to +50 CELCIUS
Time clock powered by AA baterai
Kamera Ukuran: 145x145x34mm
CARA PENGGUNAAN:
1. Hubungkan antena ke penerima.
2. Plug-in power adaptor 9V/12V DC power supply ke soket daya dari penerima (indikator daya aktif).
3. Sambungkan output dari penerima dengan monitor dengan kabel AV.
4. Plug-in power adaptor DC 8V catu daya ke soket daya dari kamera (baterai tegangan yang sama dapat diterima).
5. Fine tune ke posisi yang diinginkan (sampai citra kamera nirkabel diterima).
6. Sesuaikan lensa kamera ke posisi terbaik.
Anda mendapatkan:
1 * Wireless Color Camera with Built-in Microphone
1 * Wireless Flip-tipe 4-channel AV Receiver
1 * 8V Power Adaptor untuk Camera
1 * 9V Power Adaptor untuk Receiver
1 * Swivel Bracket for Camera
1 * Antenna for Receiver
1 * Kabel AV
Price: $90
